DescriptionSpeed-X SP-9260 2D CMOS Wired Desktop Barcode ScannerThe Speed-X SP-9260 is a reliable wired desktop barcode scanner designed for use in retail stores, POS counters, warehouses, and offices. It quickly and accurately scans both 1D and 2D barcodes with automatic sensing and a stable USB connection. With a wide scanning angle, strong barcode reading ability, and durable design, the SP-9260 is ideal for everyday high-volume scanning.Wired Desktop Barcode Scanner Technical SpecificationsElectrical CharacteristicsInterface Supported: USB HID Keyboard / USB VCPInput Voltage: DC 5V ±5%Current: Max 335mAOptical CharacteristicsImage Sensor: CMOS Array SensorSensor Resolution: 640 × 480 pixelsLight Aimer: 617 nm LEDIndication: Buzzer & LEDTrigger Mode: Auto-sense, ButtonDecoding Speed: 60 FPSPerformance CharacteristicsScanning Angle:Pitch: ±55°Skew: ±55°Tilt: ±360°Field of View: 43° (H), 33° (V)Minimum Resolution:1D ≥ 4 mil2D ≥ 5 milMinimum PCS Value: ≥ 20% (UPC/EAN 13, 13 mil)Language Support: Multiple LanguagesData Editing: Supports custom data outputDecode Capability1D Barcodes Supported: Codabar, Code 39, Interleaved 2 of 5, NEC 2 of 5, Code 93, Straight 2 of 5 Industrial, Straight 2 of 5 IATA, Matrix 2 of 5, Code 11, Code 128, GS1-128, UPC-A, UPC-E0, UPC-E1, EAN/JAN-13, EAN/JAN-8, MSI, GS1 DataBar Omnidirectional, GS1 DataBar Limited, GS1 DataBar Expanded, China Post (Hong Kong 2 of 5), GS1 Composite Codes, Codeblock A, Codeblock F, Code 32, ISSN, ISBN2D Barcodes Supported: PDF417, QR Code, Data Matrix, Aztec Code, HanXin Code, Maxi Code, Micro PDF417, GS1 CompositePhysical CharacteristicsDimensions: 85 × 85 × 140 mm (L × W × H)Weight: 370 gIndicators: Beeper, LEDEnvironmental CharacteristicsOperating Temperature: -20°C to 60°CHumidity: 5% to 95% RH (non-condensing)Storage Temperature: -30°C to 70°CShock Resistance: 1.5 m drop onto a concrete surfaceWired Desktop Barcode Scanner Decoding Depth of FieldSymbologyResolutionNearestFarthestCode 395 mil10 mm90 mmCode 3913 mil0 mm175 mmUPC-A3.34 mil10 mm170 mm>QR Code20 mil0 mm130 mmQR Code30 mil0 mm180 mmPay Code (QR 3 × 3 cm)—10 mm320 mmPay Code (QR 2.3 × 2.3 cm)—0 mm260 mm
